Infrared Multifunctional Thermometer
Measurement method： Non contact Storage temperature： -20℃ ~+55℃≤93%RH Measuring distance： 3cm-5cm measuring range ：34.0℃ -42.6℃ measurenent accuracy：35.0℃~42.0℃ within t0.2℃ 35.0℃~42.0℃ Outside t0.3℃ Power Supply： DC 3V(2 No.7 batteries) Automatic Power-off：No operated within 30 seconds Package size：40mm*40mm*150mm weight：64g Operating environment：16℃~35℃ RH≤85%
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Description
Products Description
Product background: Frontal thermometer is a non-contact temperature measurement tool, especially suitable for rapid screening of fever symptoms, commonly used in various occasions such as public health, homes, hospitals, etc.
For situations that require rapid and accurate temperature measurement, the forehead thermometer provides a convenient and hygienic solution.
Non contact measurement: Users can complete temperature measurement without touching the forehead thermometer, reducing the risk of cross infection.
Quick reading:
The forehead temperature gun usually displays measurement results within a few seconds, making it suitable for rapid screening in densely populated areas.
Accuracy:
A high-quality forehead thermometer can provide accuracy comparable to ear or armpit temperature.
Easy to use:
Usually, just aim your forehead and press the measurement button to obtain a temperature reading.
Technical advantages:
Infrared temperature measurement technology: The forehead temperature gun uses infrared sensors to measure the temperature of the forehead skin, and calculates the corresponding internal temperature through algorithms.
Temperature compensation:
Some forehead temperature guns have environmental temperature compensation function, which can maintain measurement accuracy in different environments.
Design philosophy:
Ergonomic design: Frontal temperature guns are usually designed with a comfortable grip shape for long-term use.
Visual display:
Large screen LCD display, easy to read measurement results, and some models also have backlight function.
Measurement range:
The measurement range of the forehead temperature gun is usually between 34 ℃ and 42 ℃.
Resolution:
A high-resolution forehead temperature gun can display temperature changes of 0.1 ℃ or less.
Public health:
used in places such as airports, train stations, schools, etc. for rapid screening of febrile populations.
Home use:
Convenient for daily temperature monitoring by family members, especially children and the elderly.
Medical facilities:
used for temperature monitoring in hospitals, clinics, and other places to reduce the risk of contact transmission.
Mercury free design:
The forehead temperature gun does not use mercury, avoiding environmental pollution and health risks.
Automatic shutdown:
Some temperature guns will automatically shut down after a period of inactivity, saving electricity and extending their service life.
Service and Support:
Provide product manuals, warranty cards, and customer service hotlines or online support to answer user questions.
Products information
Products Function
specification of HS-114 Infrared thermometer
| Measurement method | Non contact |
| Storage temperature | -20℃ ~+55℃≤93%RH |
| Measuring distance | 3cm-5cm |
| Measuring range | 34.0℃ -42.6℃ |
| Measurenent accuracy | 35.0℃~42.0℃ within ±0.2℃ 35.0℃~42.0℃ Outside ±0.3℃ |
| Power Supply | DC 3V(2 No.7 batteries) |
| Automatic Power-off | No operated within 30 seconds |
| Package size | 40mm*40mm*150mm |
| weight | 64g |
| Operating environment | 16℃~35℃ RH≤85% |
Scope of application
This product measures the body temperature by collecting the infrared thermal radiation from the human forehead and hair. Its operation is simple and sanitary.and its measurement is fast and accurate. The user only needs to point the detector head at the forehead and press the measurement key. In one second, the user can quickly and accurately measure the body temperature, which can be used by families measure the body temperature.
Precautions
•Before use, please read this manual carefully and confirm that the battery has been installed.
•Do not immerse the forehead temperature gun in any liquid.
•It is forbidden to use under the environment of too high or too low temperature for a long time.
•Collision, falling and mixing with sharp objects are prohibited.
•Do not disassemble by yourself.
•Do not use in strong electromagnetic interference environment.
•Put the forehead temperature gun out of the reach of children.
•Measurement results are not a substitute for physician diagnosis.
•In case of failure, please contact the seller or manufacturer.
Installation and use instructions
The product is mainly composed of infrared temperature sensor, signal receiving processor, key, buzzer, LCD display, battery, etc.
Physical Display
